Product Description
The machine tool named hydraulic folding machine adopts welded steel plate construction and eliminate internal stress by heat treatment, assuring the hydraulic folding machine high strength, good rigidity, small deformation, easy operation and high endurance.

1. Hydraulically operated bending and clamping beam of CNC hydraulic folding machine for efficient heavy duty operation

2. The CNC hydraulic folding machine has high structural rigidity from heavy plate steel box construction with continuous welded seams

3. Bending beam of CNC hydraulic folding machine powered by dual hydraulic cylinders

4. The CNC hydraulic folding machine is fully integrated and enclosed electric / hydraulic system with large oil reservoir to maintain low oil temperature

5. The CNC hydraulic folding machine has high load capacity dual spherical plane bearings utilized at bending beam pivots and over-centre clamp bearings.

6. The CNC hydraulic folding machine has precise electric / hydraulic controls with manual inching of bending beam

7. Utilization of easy to set micro-switches on the CNC hydraulic folding machine provides accurate & infinitely adjustable angle control to the folding apron

8. The CNC hydraulic folding machine has comprehensive equipment protection from electric and hydraulic overload systems

9. Hydraulic System of the CNC hydraulic folding machine: high quality component ensures reliable performance for years of continuous operation; powerful direct coupled hydraulic pump and motor provides efficient, rapid operation; unique electric / hydraulic control ensures safe and simple operation

10. Section clampers of the CNC hydraulic folding machine is suitable for producing disk, box etc.

11. Open height of the CNC hydraulic folding machine is up to 110mm

12. Servo motor drives scotch to position back gauge of the CNC hydraulic folding machine is precisely and rapidly.

13. CNC control on the CNC hydraulic folding machine for bending angle and back gauge (double axis) The CNC hydraulic folding machine can be used for the material up to 5mm thickness from 1320mm to 3200mm width.
