YD32 series small Hydraulic press

Product Description

Heavy 4-post frame provides maximum rigidity and minimum deflection for accurate parts and long tool life. Thick plates and large columns provide you with the stable platform you need for your demanding application.

Long bearing length offer improved stability and resistance to off-center loading.

PLC press control is flexible and safe. PLC controls allow for customized press cycles.

 Dual Palm Button control: anti-tie down, non-repeat controls with ring guards; conforms to OSHA.

Adjustable proximity switches allows stroke adjustments in seconds.

Pressure control and gauge allow tonnage adjustment in seconds.

Selector switch modes of operation: jog (setup) and run (cycle).

Wide range of hydraulic systems to match your requirements.

Large reservoirs minimize the need for oil coolers.

Large daylight accommodates large dies. Special daylights and bed sizes are available.

Long stroke lengths are adjustable from about 1" to maximum. Special stroke lengths are available.

Pressure and distance reversal systems are standard.
