J21S Deep Throat Press

0.00
0.00

Product Description
We provide a huge gamut of precise engineered power press machines that include C type power press, pillar type power press etc. To assure the quality of the power press machines, they are manufactured from the genuine raw materials that are procured from the reliable vendors. Heavy duty power press machines are perfect for pressing, trimming, straightening, assembly and disassembly of various components. Long lasting trouble free performance, low maintenance and high speed are some of its salient features. We have carved a niche as one of the distinguished power press machines exporters from China.

Frame : The frame is made of steel construction and their heavy cross section and rigid design assure minimum deflection and accurate alignment cast iron legs will be supplied up to 30 ton press.

Crank Shaft : Crank Shaft materials are made of special alloy steel to withstand the effective load sitted in busher with high accuracy.

Gears Clutch : The Gears are made of cast steel or fabricated and it teeth are generated by hobbing. The clutch is provided of Pin / Rolling key type also it is rigid and well supported for the mass production clutch can gives continuous stoke.

Flywheel : The Flywheel is made of high grade castiron and is balanced for storng and releasing adequate energy for the pressing operations.

Lubrication : An accurate Lubrication system has been proved for lubrications the sliding surface and moving parts.

Table & Ram : Table and Ram are mad of high grade heavy duty cast iron & properly seasoned. They are perfectly aligned to bach other to obtain high accuracy & precision press operation.
